23
Basic operation
Menu bar
①
PC adjust menu
Adjust computer parameters to match with VGA input signal format: auto PC adj, Fine sync,
Total dots, Horizontal, Vertical, Clamp,Display area H, Display area V.
②
Screen menu
If a computer is selected as a signal source, the following setup options for the image size are
available: Normal, True, Full, Wide, Custom, Advanced or Digital zoom +/-.
If video equipment is selected as a signal source, the following setup options for the image size
are available: Normal,Full, Wide or Custom.
③
Image select menu
The available image modes are: Dynamic, Normal, Cinema, Blackboard (green), Colorboard
or User Image.
④
Image adjust menu
If a computer is selected as a signal source, the following image adjusting options are available:
Contrast, Brightness,Color temp., White balance (R/G/B), Sharpness and Gamma.
If video equipment is selected as a signal source, the following image adjusting options are
available: Contrast, Brightness,Color, Tint, White balance (R/G/B), Sharpness, Gamma,
Noise reduction and Progressive.
⑤
Input menu
Select input source: HDMI 1, HDMI 2, HDMI 3, Display Port, DVI, VGA 1, VGA 2, Component,
S-Video, Video 1, Video 2, RGBHV, Scart, Network, Card Reader, USB Autorun.
⑥
Sound menu
Adjust the volume level or mute the sound.
⑦
Setting menu
Congure operation settings of the projector.
⑧
Advanced setting menu
Congure advanced operation settings of the projector.
⑨
Network menu
Access the network function.
⑩
Infomation menu
To display the system information of the projector.
Main menu
Sub menu
Exit Move Next Next
- - - -
PC adj.
Auto PC adj.
Fine sync 16
Total dots 1344
Horizontal 296
Vertical 35
Clamp 1
Display area H 1024
Display area V 768
Reset
Mode free
Stored
①
② ③ ④
⑤ ⑥
⑦
⑧ ⑨
⑩
