Basic operation
Auto setup
Keystone correction
This function is available just by pressing the
AUTO SETUP button on the side control or
AUTOSET button on the remote control. The
system then automatically performs various
settings in the setup menu, including input
source search , auto pc adjust and auto focus .
If a projected picture has keystone distortion,
follow the steps below to manually correct the
image.
Press the KEYSTONE button on the remote
control. The keystone dialog box appears.
Correct keystone distortion with

buttons. Keystone adjustment can be stored.
Reduce the upper
width with

button.
Reduce the left
width with

button.
Reduce the right
width with

button.
Reduce the lower
width with

button.
● The arrows are white when there is no
correction.
● The arrows that are used for correction turns
red.
● The arrows disappear at the maximum
correction.
● If you press the KEYSTONE button on the
remote control once more while the keystone
dialog box is being displayed, the keystone
adjustment is canceled.
● The adjustable range can be limited
depending on the input signal.
Side control
Remote control
AUTO SETUP
button
AUTOSET
button
KEYSTONE button
Point

button



KeystoneKeystone

