33
Fitting and installation
EN
Version with follower
1
2
3
3
2
5
3
4
1
1
Optional for adjustable
striking plate versions
1
Hinweis!
A short escutcheon must be used for a backset of 35 mm: With a backset
of 35 mm, the Technilock
®
L4 does not provide an opening for the upper fi-
xing screw of a long escutcheon. Therefore, a fitting with short escutcheon
must be used.
I
3
2
5
3
4
1
1
1
for
backset > 35 mm
only
Fig. 5 : Install the lock (versions with and without follower)
