Front door fitting
Long escutcheon protection rating 2 (only for version with follower, 60 mm backset) N44274109200000
Long escutcheon protection rating 4 (only for version with follower, 60 mm backset) N44274109400000
Short escutcheon 844S6B4 – – – – – – – –
Additional adapter board
The additional adapter board shown in the chapter “Electrical connection”, page 34, Fig. 7 for an
expandable electrical connection is not included in the scope of delivery of the Technilock
®
L4. The
additional board is only suitable for Technilock
®
L4 without follower. The supplementary board can be
ordered separately:
effeff – Supplementary board for Technilock
®
L4 844L4ZBP1 – – – – 00
Cable
The cable type specified in the chapter “Power supply”, page 35 is not included in the scope of delivery
of the Technilock
®
L4. The cable can be ordered separately:
effeff – Connection cable for Technilock
®
L4 844ZBKAB01 – – – 00
Power supply
The mains adapter with adjustable output voltage specified in the chapter “Power supply”, page 35 is
not included in the scope of delivery of the Technilock
®
L4. The mains adapter can be ordered separately:
effeff – Mains adapter for Technilock
®
L4 effeff 1003–24–4 – – – – 10
Property Characteristic
Input voltage 90 V – 260 V AC
Output voltage, adjustable 24 V DC, stabilised
Output current
(Current limiting on the output current with auto-
matic restarting)
4 A
Ambient temperature range –20°C – +40°C
Housing Synthetic material with screw connection terminals
only for Technilock
®
L4
without follower
Order supplementary
board
Order connection cable
