Accessories
EN
Strike plates
Additional information
The Technilock
®
L4 only functions with matching striking plates equipped with two adhered disc magnets.
Striking plates from the series L3, M4 or L3s cannot be used.
I
Standard Adjustable
844L4SBL1----01 844L4SBL3----01
7
17,2
34
Ø5,5
7
109
52,9 47
251
265
187
18 7
3
R5
49,4 13
7
27
34
Ø5,5
7
109 91
52,9 47
251
265
18
187 7
3
R5
20
49,4 13
18
Accessories
