Min-Fail: This message appears on the display, if the measured reading drops below the Min
Lmt current setting of the AC/DC Withstand test, or Min Lmt resistance setting of the
Insulation Resistance test.
Cont. Max: This message appears on the display, if the measured reading exceeds the Max
Lmt continuity resistance setting and the Continuity function is set to ON of the AC/DC
Withstand test.
Cont. Min: This message appears on the display, if the measured reading drops below the Min
Lmt continuity resistance setting and the Continuity function is set to ON of the AC/DC
Withstand test.
Arc-Fail: This message appears on the display, if the DUT arcing current exceeds the Arc
Sense limit and Arc function is active (Arc Sense = 1… 9) of the AC/DC Withstand test.
Short: This message appears on the display, if the DUT current is well beyond the metering
range of the test.
Breakdown: This message appears on the display, if the DUT current is well beyond the
metering range of the test and the arcing condition is beyond the arc sense limit.
GND-Fault: This message appears on the display, if the GFI threshold is exceeded during the
test.
Out-Error: This message appears on the display, after exiting from the Output Error screen. If
the instrument has an internal problem and the TEST button is pressed, the Output Error screen
will appear as follows:
The RESET button is not active while this screen is displayed. To clear this screen and return
to test mode the Exit soft key must be pressed. When the Exit soft key is pressed the
instrument will continue with its normal failure indication process. The failure light and Alarm
can then be cleared by pressing the RESET button.
Output Error
Device malfunction
Setting = x.xxkV
Reading = x.xxkV
Press Exit to
continue or call
1-800-858-8378.
