(1) "Valid ASCII" is the character set that is available from the front panel LCD user
interface. Consisting of upper case alphabet (A-Z), numbers (0-9) and decimal
point (.), asteric (*), dash (-), underbar (_), tilde (~) and space (SP).
FL <file number>
Load a file from non-volatile memory into random access memory RAM.
FD
Deletes the file loaded into RAM from the non-volatile memory space as well as RAM.
A new file must be loaded before and tests can be run.
FD <file number>
Deletes a file from non-volatile memory indicated by the file number.
FS
Saves the file from RAM to the non-volatile memory space.
FSA {<file number>,<file name>}
Saves the current file from RAM into the non-volatile memory space with the indicated
file number and file name. The original file will not be modified with this operation. If
there is a file already located at the desired number it will be moved to the next higher
number and inserted in its place. New files may be added to the bottom of the file list
but there must not be any numbers that do not have a file defined.
FN {<file number>,<file name>}
Creates a new file name at the specified file number. If there is a file already located
at the desired number it will be moved to the next higher number and inserted in its
place. New files can be added to the bottom of the file list but there must not be any
numbers that do not have a file defined.
SS <step number>
Selects the active selected step to load into RAM. The step must first be selected
before any specific parameters can be edited.
ADD <test,p1,p2,p3…>
This command inserts or adds a new step to the test sequence. This command will
add or insert the test at the step location that has been selected. When a test has
already been created at a selected step then the new step will be inserted and the
previous step will move down to the next step and all other step will be renumbered
accordingly.
The parameter <test> indicated the test type. The values ACW, DCW, IR, GND,
