Associated Research OMNIA II 8207 User Manual

238
Range 4
0.0uA ~ 126.0uA, frequency 15Hz
- 1MHz
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
15Hz < f < 100KHz : add ±(2% of
reading + 0.2% of range) to base
accuracy
100KHz < f < 1MHZ : add ±(2% of
reading + 0.5% of range) to base
accuracy
Range 5
0.0uA ~ 504uA, frequency 15Hz
- 1MHz
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
15Hz < f < 100KHz : add ±(2% of
reading + 0.2% of range) to base
accuracy
100KHz < f < 1MHZ : add ±(2% of
reading + 0.5% of range) to base
accuracy
Range 6
0.0uA ~ 600uA, frequency DC –
100KHz
Resolution
1uA
Additional Error
DC: add ±(2% of reading + 0.2% of
range) to base accuracy
15Hz < f < 100KHz : add ±(2% of
reading + 0.2% of range) to base
accuracy
DISPLAY AUTO RANGE
Touch Current Display (Peak) (AC
Only)
Range 1
0.0uA ~ 32.0uA, frequency DC, 15Hz
– 1MHz
Resolution
0.1uA
Accuracy
15Hz < f <1MHz: ±(10% of reading +
2uA)
Range 2
28.0uA ~ 130.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
15Hz < f <1MHz: ±(10% of reading +
2uA)
Range 3
120.0uA ~ 525.0uA, frequency DC,
15Hz - 1MHz
Resolution
0.1uA
Accuracy
15Hz < f <1MHz: ±(10% of reading +
2uA)
