85
Appendix B
Optional spare battery (purchased separately)
5. Insert a new alkaline battery (9V, size 1064A, purchased separately)
following the polarity label in the battery compartment.
6. Replace the battery compartment cover and tighten the screw. Replace the
battery compartment screw with a Phillips screwdriver.
7. For desktop mode, reattach the bracket to the telephone base by sliding
the tabs into the holes as shown. Snap the bracket into the telephone base.
Then see pages 11 and 12 to reinstall the telephone line cord.
NOTES:
If there is a power failure when a working battery is installed:
• The telephone screen shows
AC FAIL.
• You can use the handset to make or answer outside calls.
• The handset volume is at the minimum level and only the two lowest levels
are available for the ringer volume.
