Atmel ATtiny26

139
ATtiny26(L)
1477G–AVR–03/05
Figure 86. Idle Supply Current vs. V
CC
(32 kHz External Oscillator)
Power-down Supply Current Figure 87. Power-down Supply Current vs. V
CC
(Watchdog Timer Disabled)
IDLE SUPPLY CURRENT vs. V
CC
32kHz EXTERNAL OSCILLATOR
0
5
10
15
20
25
30
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
25°C
POWER-DOWN SUPPLY CURRENT vs. V
CC
WATCHDOG TIMER DISABLED
0
0.2
0.4
0.6
0.8
1
1.2
1.4
1.6
1.8
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
85°C
25°C
-40°C
