Figure 94. Standby Supply Current vs. V
CC
(4 MHz XTAL, Watchdog Timer Disabled)
Figure 95. Standby Supply Current vs. V
CC
(6 MHz Resonator, Watchdog Timer
Disabled)
STANDBY SUPPLY CURRENT vs. V
CC
4 MHz XTAL, WATCHDOG TIMER DISABLED
0
20
40
60
80
100
120
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
STANDBY SUPPLY CURRENT vs. V
CC
6 MHz RESONATOR, WATCHDOG TIMER DISABLED
0
20
40
60
80
100
120
140
160
2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
I
CC
(uA)
