Figure 114. Reset Pin as I/O – Pin Hysteresis vs. V
CC
Figure 115. Reset Input Threshold Voltage vs. V
CC
(V
IH
, Reset Pin Read as “1”)
RESET PIN AS I/O - PIN HYSTERESIS vs. V
CC
0
0.1
0.2
0.3
0.4
0.5
0.6
0.7
22.533.544.555.5
V
CC
(V)
Threshold (V)
85°C
25°C
-40°C
RESET INPUT THRESHOLD VOLTAGE vs. V
CC
VIH, RESET PIN READ AS '1'
0
0.5
1
1.5
2
2.5
1.5 2 2.5 3 3.5 4 4.5 5 5.5
V
CC
(V)
Threshold (V)
85°C
25°C
-40°C
