34. BSET – Bit Set in SREG
34.1. Description
Sets a single Flag or bit in SREG.
Operation:
(i) SREG(s) ← 1
Syntax: Operands: Program Counter:
(i) BSET s 0 ≤ s ≤ 7 PC ← PC + 1
16-bit Opcode:
1001 0100 0sss 1000
34.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
⇔ ⇔ ⇔ ⇔ ⇔ ⇔ ⇔ ⇔
I 1 if s = 7; Unchanged otherwise.
T 1 if s = 6; Unchanged otherwise.
H 1 if s = 5; Unchanged otherwise.
S 1 if s = 4; Unchanged otherwise.
V 1 if s = 3; Unchanged otherwise.
N 1 if s = 2; Unchanged otherwise.
Z 1 if s = 1; Unchanged otherwise.
C 1 if s = 0; Unchanged otherwise.
Example:
bset 6 ; Set T Flag
bset 7 ; Enable interrupt
Words 1 (2 bytes)
Cycles 1
Atmel AVR Instruction Set Manual [OTHER]
Atmel-0856L-AVR-Instruction-Set-Manual_Other-11/2016
61
