Atmel AVR User Manual

16-bit Opcode:
(i) 1000 001r rrrr 1000
(ii) 1001 001r rrrr 1001
(iii) 1001 001r rrrr 1010
(iv) 10q0 qq1r rrrr 1qqq
119.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – – – – – – –
Example:
clr r29 ; Clear Y high byte
ldi r28,$60 ; Set Y low byte to $60
st Y+,r0 ; Store r0 in data space loc. $60(Y post inc)
st Y,r1 ; Store r1 in data space loc. $61
ldi r28,$63 ; Set Y low byte to $63
st Y,r2 ; Store r2 in data space loc. $63
st -Y,r3 ; Store r3 in data space loc. $62(Y pre dec)
std Y+2,r4 ; Store r4 in data space loc. $64
Words 1 (2 bytes)
Cycles 2
Cycles XMEGA (i) 1
(ii) 1
(iii) 2
(iv) 2
Cycles Reduced Core tinyAVR (i) 1
(ii) 1
(iii) 2
