115. SLEEP
115.1. Description
This instruction sets the circuit in sleep mode defined by the MCU Control Register.
Operation:
(i) Refer to the device documentation for detailed description of SLEEP usage.
Syntax: Operands: Program Counter:
(i) SLEEP None PC ← PC + 1
16-bit Opcode:
1001 0101 1000 1000
115.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – – – – – – –
Example:
mov r0,r11 ; Copy r11 to r0
ldi r16,(1<<SE) ; Enable sleep mode
out MCUCR, r16
sleep ; Put MCU in sleep mode
Words 1 (2 bytes)
Cycles 1
Atmel AVR Instruction Set Manual [OTHER]
Atmel-0856L-AVR-Instruction-Set-Manual_Other-11/2016
168
