Atmel AVR User Manual

11. BCLR – Bit Clear in SREG
11.1. Description
Clears a single Flag in SREG.
Operation:
(i) SREG(s) ← 0
Syntax: Operands: Program Counter:
(i) BCLR s 0 ≤ s ≤ 7 PC ← PC + 1
16-bit Opcode:
1001 0100 1sss 1000
11.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
⇔ ⇔ ⇔ ⇔ ⇔ ⇔ ⇔ ⇔
I 0 if s = 7; Unchanged otherwise.
T 0 if s = 6; Unchanged otherwise.
H 0 if s = 5; Unchanged otherwise.
S 0 if s = 4; Unchanged otherwise.
V 0 if s = 3; Unchanged otherwise.
N 0 if s = 2; Unchanged otherwise.
Z 0 if s = 1; Unchanged otherwise.
C 0 if s = 0; Unchanged otherwise.
Example:
bclr 0 ; Clear Carry Flag
bclr 7 ; Disable interrupts
Words 1 (2 bytes)
Cycles 1
