44. CLS – Clear Signed Flag
44.1. Description
Clears the Signed Flag (S) in SREG (Status Register).
Operation:
(i) S ← 0
Syntax: Operands: Program Counter:
(i) CLS None PC ← PC + 1
16-bit Opcode:
1001 0100 1100 1000
44.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – – 0 – – – –
S 0
Signed Flag cleared.
Example:
add r2,r3 ; Add r3 to r2
cls ; Clear Signed Flag
Words 1 (2 bytes)
Cycles 1
