78. LSR – Logical Shift Right
78.1. Description
Shifts all bits in Rd one place to the right. Bit 7 is cleared. Bit 0 is loaded into the C Flag of the SREG.
This operation effectively divides an unsigned value by two. The C Flag can be used to round the result.
Operation:
(i)
→
0
→
b7 - - - - - - - - - - - - - - - - - - b0
→
C
Syntax: Operands: Program Counter:
(i) LSR Rd 0 ≤ d ≤ 31 PC ← PC + 1
16-bit Opcode:
1001 010d dddd 0110
78.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – – ⇔ ⇔ 0 ⇔ ⇔
S N ⊕ V, for signed tests.
V N ⊕ C, for N and C after the shift.
N 0
Z R7 • R6 • R5 • R4 • R3 • R2 • R1 • R0
Set if the result is $00; cleared otherwise.
C Rd0
Set if, before the shift, the LSB of Rd was set; cleared otherwise.
R (Result) equals Rd after the operation.
Example:
add r0,r4 ; Add r4 to r0
lsr r0 ; Divide r0 by 2
Words 1 (2 bytes)
Cycles 1
Atmel AVR Instruction Set Manual [OTHER]
Atmel-0856L-AVR-Instruction-Set-Manual_Other-11/2016
122
