6. ADD – Add without Carry
6.1. Description
Adds two registers without the C Flag and places the result in the destination register Rd.
Operation:
(i) (i) Rd ← Rd + Rr
Syntax: Operands: Program Counter:
(i) ADD Rd,Rr 0 ≤ d ≤ 31, 0 ≤ r ≤ 31 PC ← PC + 1
16-bit Opcode:
0000 11rd dddd rrrr
6.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – ⇔ ⇔ ⇔ ⇔ ⇔ ⇔
H Rd3 • Rr3 + Rr3 • R3 + R3 • Rd3
Set if there was a carry from bit 3; cleared otherwise.
S N ⊕ V, for signed tests.
V Rd7 • Rr7 • R7 + Rd7 • Rr7 • R7
Set if two’s complement overflow resulted from the operation; cleared otherwise.
N R7
Set if MSB of the result is set; cleared otherwise.
Z R7 • R6 • R5 • R4 • R3 • R2 • R1 • R0
Set if the result is $00; cleared otherwise.
C Rd7 • Rr7 + Rr7 • R7 + R7 • Rd7
Set if there was carry from the MSB of the result; cleared otherwise.
R (Result) equals Rd after the operation.
Example:
add r1,r2 ; Add r2 to r1 (r1=r1+r2)
add r28,r28 ; Add r28 to itself (r28=r28+r28)
Words 1 (2 bytes)
Cycles 1
Atmel AVR Instruction Set Manual [OTHER]
Atmel-0856L-AVR-Instruction-Set-Manual_Other-11/2016
32
