104. SBRC – Skip if Bit in Register is Cleared
104.1. Description
This instruction tests a single bit in a register and skips the next instruction if the bit is cleared.
Operation:
Operation:
(i) If Rr(b) = 0 then PC ← PC + 2 (or 3) else PC ← PC + 1
Syntax: Operands: Program Counter:
(i) SBRC Rr,b 0 ≤ r ≤ 31, 0 ≤ b ≤ 7 PC ← PC + 1, Condition false -
no skip
PC ← PC + 2, Skip a one word
instruction
PC ← PC + 3, Skip a two word
instruction
16-bit Opcode:
1111 110r rrrr 0bbb
104.2. Status Register (SREG) and Boolean Formula
I T H S V N Z C
– – – – – – – –
Example:
sub r0,r1 ; Subtract r1 from r0
sbrc r0,7 ; Skip if bit 7 in r0 cleared
sub r0,r1 ; Only executed if bit 7 in r0 not cleared
nop ; Continue (do nothing)
Words 1 (2 bytes)
Cycles 1 if condition is false (no skip)
2 if condition is true (skip is executed) and the instruction skipped is 1 word
3 if condition is true (skip is executed) and the instruction skipped is 2 words
