Atomos SUMO19 User Manual

*Subject to change without notice Atomos Sumo19 – User Manual Edition 1: September 2017 18
Lock the Display Screen
You can lock the display of the Sumo19 so that no
changes can be made by mistakenly touching the
screen, to lock the Sumo19 simply short tap the power
button. Short tap the power button again to unlock the
unit.
The lock screen can be combined with the display
off function so that when lock is engaged the display is turned off.
The Tally light on the front of the unit will still display Rec (Red) or idle
(green) status. Locking of the display can be found in the Monitor
Mode.
Timecode
TakesyoutothededicatedTimecodecongurationpage.
Refer to Page 36 of this manual for more information.
Sumo19 Info
Showsthesoftware(rmware)versionanduniquedevice
ID (DID) of your Sumo19 device. This will be required
to activate the Avid DNxHD / Avid DNxHR codec. You
can also check on the Atomos website to ensure you are
runningthelatestrmware:
http://www.atomos.com/support
Remember that pressing on the Back button will
always take you back to the previous menu.
7. Using the Sumo19 cont.
UNLOCKED
LOCKED
UNLOCKED
LOCKED
UNLOCKED
LOCKED

Atomos SUMO19 Specifications

General

Product color	Black
Housing material	Aluminum
Video capturing speed	120 fps
Maximum video resolution	3840 x 2160 pixels
DC voltage	16.8 V
Power consumption (typical)	75 W
Built-in display	Yes
Display diagonal	19 \
Display resolution	1920 x 1200 pixels
BNC input ports	1
HDD size	2.5 \

Weight and Dimensions

Depth	63 mm
Width	504 mm
Height	310 mm
Weight	5450 g
