Atomos SUMO19 User Manual

*Subject to change without notice Atomos Sumo19 – User Manual Edition 1: September 2017 47
SpecicationscorrectattimeofprintingE&OE
Weight and Dimensions
Without batteries & media
5.47kg / 12lb
With batteries & media
-
With stand & Battwing adapter
6.28kg / 13.8lb
Dimensions (W x H x D mm)
506 x 310 x 62.5mm, 19.9" x 12.2" x 2.5" (without stand)
506x330x180mm,19.9”x13”x7.1”(withstand)
Construction
Aluminium alloy chassis with built in armor protection
Mounting points
1/4-20 screw; 4 x top, 4 x bottom, 2 x side
3/8-16 screw; 2 x top, 2 x bottom, 1 x side
VESA mount rear
Power
Operating power
75W
Compatible batteries
V-Lock / Anton Bauer via XLR terminal
(optional mounting plates available)
Input voltage (battery)
14.4V nominal
Battery time (based on 7.4V)
DependsonWattHoursspecicationofbatteryused
-
-
DC In
1 x XLR (12-16.8V)
Continuous power
* Patent pending
Primary-secondary battery system.
Change batteries without losing power
Loop batteries continuously.
Touchscreen
Size
19"
Resolution / PPI
1920 x 1080 / 120PPI
Aspect ratio
16:9 native
Color Gamut
REC709 HDTV
Look up table (LUT) support
3D LUT (.cube format)
Anamorphic de-squeeze
2x, 1.5x, 1.33x, Panasonic 8:3
Technology
SuperAtom IPS panel (capacitive touch), calibration to
Rec.709 with optional calibration unit
HDR
AtomHDR
Yes
Supported Log formats
Sony SLog2 / SLog3, Canon CLog / CLog 2, Arri Log C,
Panasonic Vlog, JVC JLog, Red LogFilm
Supported Gamuts
Sony SGamut / SGamut3 / SGamut3.cine, Canon Cine-
ma / BT2020 / DCI P3 / DCI P3+, Panasonic V Gamut,
Arri Alexa Wide Gamut
Bit depth
10-bit (8+2 FRC)
Brightness
1200nit (+/- 10%)
HDR input (PQ/HLG)
Yes / Yes
HDR output (PQ/HLG)
Yes / Yes
Video Input (Loop Out)
HDMI
1 x HDMI (2.0)
SDI
Quad link 4 x 3G SDI* or up to 12G single link SDI
Signal
Uncompressed true 10-bit or 8-bit 422 (camera
dependent)
Video Output (Play Out)
HDMI
1 x HDMI (2.0)
SDI
1x4K-SDI12G/6GorHD-SDI3G/1.5G
Signal
Uncompressedtrue10-bitor8-bit422(playbackle
dependent)
Supported Loop Out Formats
HDMI to HDMI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/100/120
2160p 24/25/30/50/60
SDI to SDI
720p 50/60, 1080i 50/60
1080pSF 24/25/30
1080p 24/25/30/50/60/100/120
2160p 24/25/30/50/60
Video Signal Conversion
HDMI to SDI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/100/120
2160p 24/25/30/50/60
SDI to HDMI
720p 50/60, 1080i 50/60,
1080p 24/25/30/50/60/100/120
2160p 24/25/30/50/60
Supported Codecs & Frame Rates (Record & Playback)
Raw Record
Brand / Model / Codec Resolution / Frame rate
Sony^^ FS5/FS7/FS700
CDNG
4KDCI;24/25/30p
4KUHD;notsupportedincamera
2K;24/25/30/50/60/100/120p
1080; not supported in camera
CanonC300MKII/C500
CDNG
4KDCI;24/25/30p
4KUHD;24/25/30p
2K;notsupportedincamera
1080; not supported in camera
Panasonic VaricamLT /
Varicam35*
CDNG
4KDCI;24/25/30p
4KUHD;24/25/30p
2K;notsupportedincamera
1080; not supported in camera
Arri Alexa Mini
.ARI*
2880x1620*; 24/25/30/50/60p
2880x2160*; 24/25/30/50/60p
Raw to ProRes /
DNxHR
Brand / Model / Codec Resolution / Frame rate
Sony^^ FS5/FS7/FS700
ProRes (HQ, 422, LT)
DNxHR (HQX, HQ,
SQ, LB)
4KDCI;24/25/30/50/60p
4KDCIBurst;120p*(SonyFSseries)
4KUHD;notsupportedincamera
2K;24/25/30/50/60/100/120/200/240p
1080; not supported in camera
CanonC300MKII/C500
ProRes (HQ, 422, LT)
DNxHR (HQX, HQ,
SQ, LB)
4KDCI;24/25/30p
4KUHD;24/25/30p
2K;notsupportedincamera
1080; not supported in camera
Panasonic VaricamLT /
Varicam35*
ProRes (HQ, 422, LT)
DNxHR (HQX, HQ,
SQ, LB)
4KDCI;24/25/30/50*/60p*
4KUHD;24/25/30/50*/60p*
2K;notsupportedincamera
1080; not supported in camera
Video to ProRes /
DNxHR
(DNx utilizes a .MOV
wrapper)
Brand / Model / Codec Resolution / Frame rate
Codecs
Apple ProRes HQ,
422, LT
AVIDDNxHRHQX.HQ,
SQ, LB
4KDCI;24/25/30/50/60p
4KUHD;24/25/30/50/60p
2K;notsupportedincamera
1080p; 24/25/30/50/60/100^/120^/200^/240p^
1080i; 50/60i
720p; 50/60p
Onboard Processing
Pulldown removal
24/25/30pSF>24/25/30p(2:2pulldown)
60i>24p(3:2pulldown)
4K UHD downscaling
Yes - Loop-out and playback (Not available in RAW)
Audio In/Out (48kHz PCM Audio)
HDMI
2 or 8ch 24-bit, camera dependent
SDI
12ch 48kHz 24-bit
Audio
2ch balanced XLR analog in/out (direct XLR connec-
tion)
Dynamicrange>90dB
Max signal level +24dBu
Max analog gain +52dB
48V Phantom Power for Mic
Headphone out
3.5mm
Built-in speakers
Yes
Remote Start/Stop
HDMI
Auto HDMI Trigger
Supported Protocols - Canon, Sony, Atomos Open
Standard
SDI
SDI trigger camera selectable
Other
LANC control - Slave
Playback
Playlist
Yes
Genlock / LTC
Yes
CDNG (recorded content)
No support
ProRes (recorded content)
Allrecordedlescanplayback.Playbackinslow
motion>=100fps
DNxHR / DNxHD (recorded content)
Allrecordedlescanplayback.Playbackinslow
motion>=100fps
Live Switch & Recording
ISO recording *
4 x 1080p60 Inputs
Switching *
Yes
* Future firmware update
SUMO19

Atomos SUMO19 Specifications

General

Product color	Black
Housing material	Aluminum
Video capturing speed	120 fps
Maximum video resolution	3840 x 2160 pixels
DC voltage	16.8 V
Power consumption (typical)	75 W
Built-in display	Yes
Display diagonal	19 \
Display resolution	1920 x 1200 pixels
BNC input ports	1
HDD size	2.5 \

Weight and Dimensions

Depth	63 mm
Width	504 mm
Height	310 mm
Weight	5450 g
