page 2 – 2
D-16 / Feb 2003
CONSOLE FEATURES
Console Features
Overview
The D-16 console consists of fourteen faders with associated switches, a dual
fader PHONE section, also with associated switches, a MONITOR SECTION, a
CONTROL SECTION, and a TIMER SECTION. Each section is described
below.
The basic purpose of the console is to take some of the many audio signals that
are wired to the console inputs, and generate several outputs that combine these
inputs in various groups and at various degrees of loudness, or signal strength. The
typical application is in a radio station where it is desired to develop the signals that
the station will broadcast (the on air signal), as well as several additional signals
for recording and monitoring.
