INSTALLATION and POWER
page 1 – 1
D-16 / Feb 2003
Installation and Power
Chapter Contents
Unpacking the Console ............................................................. 1-2
Countertop Mounting................................................................. 1-2
System Ground .......................................................................... 1-3
Power Supply ............................................................................. 1-5
Failsafe Dual Redundant Supply ........................................................................ 1-6
Energizing ........................................................................................................... 1-6
Audio and Control Wiring.......................................................... 1-7
Connection Procedures ...................................................................................... 1-7
Digital Audio Connections .................................................................................. 1-7
Unbalanced Connections (analog audio) ........................................................... 1-8
Installation Tip..................................................................................................... 1-8
Hand Crimp Tool Wiring Insrtuctions ...................................... 1-9
D-16 / Jul 2003
