CHAPTER2 Setting up the Phone
C435HD Users & Administrator's Manual
Device Description
Use  the  following  graphics to identify  and  familiarize  yourselfwith the device's hardware
functions.
Front View
Thefrontviewofthephoneisshowninthefigureanddescribedinthetable.
Figure 2-1: Front View
Table 2-1: Font View Description
Item # Label Name Description
1
RingLED Indicatesphonestatus:
■ Green:Idlestate
■ Flashingred:
Incomingcall(ringing)
■ Red:Answeredcall
2
LCDscreen LiquidCrystalDisplay
interactivescreenwhich
