Installation Manual 2. Mediant CCE Appliance Hardware Platforms
Version 2.0.5 9 Mediant 800 CCE & Mediant Server CCE
2 Mediant CCE Appliance Hardware
Platforms
The Mediant CCE Appliance is deployed on the following platforms:

AudioCodes Mediant 800 CCE Appliance is installed on the OSN server.

AudioCodes Mediant Server CCE Appliance is installed on an HP ProLiant server
Hyper-V Virtual machine.
Table 2-1: CCE Hardware Platforms Specifications
Appliance AudioCodes Mediant 800 CCE
Appliance
AudioCodes Mediant Server CCE
Appliance
Hardware Mediant 800 with OSN server HP ProLiant server
Processor 64-bit processor, four core (4 real
cores), 2.70 Gigahertz (GHz)
64-bit dual processor, six core (12 real
cores), 2.50 gigahertz (GHz)
RAM 32 gigabytes (GB) RAM 64 gigabytes (GB) RAM
Disk Single SSD 512 GB Four 600 GB 10K RPM 128M Cache SAS
6Gbps disks, configured in a RAID 5
configuration
NICs Two physical NICs 1Gbps + one
100Mbps
Four 1Gbps NICs
Note: The procedures described in this document are relevant for both Mediant
Appliance CCE platforms as described above. In some cases, separate procedures are
required for each platform, in which case, this is indicated.

AudioCodes Mediant 800 Specifications

General

Protocols	SIP, H.323
Digital Interfaces	1/2 E1/T1 PRI
Management	Web, CLI, SNMP
Mounting	19-inch rack
Codecs	G.711, G.729, G.722, G.723.1
Power Supply	100-240V AC
Operating Temperature	0 to 40°C
Storage Temperature	-25 to 70°C
Humidity	10% to 90% non-condensing
