AUI fb-600E - 5.40 BAUD RATE

- 41 -
5.37 DATA LENGTH
Specify the serial data bits.
Setting process:
MENU SETUP DATA LENGTH
37. DATA LENGTH ► 8 BITS ※
38. STOP BIT ► 7 BITS
5.38 STOP BIT
Specify the serial data transfer stop bit.
Setting process:
MENU SETUP STOP BIT
38. STOP BIT ► 1 BIT ※
39. PROTOCOL ► 2 BITS
5.39 PROTOCOL
Specify the protocol of printer serial data transfer as software control (XON/XOFF) or hardware control
(DTR).
Setting process:
MENU SETUP PROTOCOL
39. PROTOCOL ►
XON/XOFF ※
40. BAUD RATE ► DTR
5.40 BAUD RATE
Specify the printer serial data transfer rate.
Setting process:
MENU SETUP BAUD RATE
40. BAUD RATE ► 115200 BPS
41. PRINT DIRECH ► 57600 BPS
38400 BPS
19200 BPS
9600 BPS ※
4800 BPS
2400 BPS
1200 BPS
5.41 PRINT DIRECT
Select the printing direction of the print head: unidirectional, bidirectional or selected via software.
Setting process:
