- 76 -
Appendix B Barcode command
ESC } n R k m1 m2 v1 v2 c data (i)
HEX. 1B 7D n 52 k m1 m2 v1 v2 c data (i)
n Data count Including the total data count (besides ESC })
R R Character R
k Barcode type
Select the barcode type:
0xB1: NW 7
B2: EAN 13
B3: EAN 8
B4: Code 39
B5: Industrial 2of5
B6: Interleaved 2of5
B7: Matrix 2of5
BE: Code 128 Type B
BF: Code 128 Type C
m1,m2 barcode width
Set the barcode width:
m1*256+m2
0D: 2/180inch (default)
8D: 2/180inch
16D:2/180inch
24D:3/180inch
32D:4/180inch
v1,v2 barcode height
Set the barcode height (Value range: 192 ~ 4095):
v1*256+v2
c Verify
c: Option:
7 6543210
data (i) Barcode data data
0: check sum
1: Not print the check sum
(only used for 39 barcode
and 3 kinds 25 barcodes)
0: print character, 1: Not
print characters (apply to all
barcodes)
Disposal of EAN13 check
sum (0 : in the middle1:
0: barcode (If it is 1, it won’t
