Appendix A Self-test and Adjustment

A.1 Self-test Function

FB-600E printer supplies several print-test functions which make you run the self-test of the printer in

different states.

A.1.1 ASCII Test Mode

After install the paper (tractor paper: 136 lines, manual paper feed: A4 paper), then use the following

way to run the ASCII self-test.

z Turn on the printer, firstly, press ALT + ONLINE keys to initialize the printer, during the initialization,

press LF/FF key.

z Turn off the printer, press down LF/FF key and turn on the printer.

The printer will continuously print out ASCII characters.

A.1.2 Maintenance Printing Test (H pattern)

One page printing of H pattern is performed by turning power on, while pressing the EJECT/LOAD key.

After printing the printer will exit this test automatically. So you can send the printing command to the

printer to print.

Continuous printing of H pattern is performed by turning power on, while pressing the TEAR OFF key

and EJECT/LOAD key.

Pressing the ONLINE key can stop printing, and turn off the printer to exit H pattern mode.

A.1.3 Hex Dump Mode

Hex Dump mode can analyse if there is any malfunction in the interfaces of the printer and the

computer.

z Turn on the printer, firstly, press ALT + ONLINE keys to initialize the printer, during the

initialization, press HIGH SPEED key to enter Hex Dump printing.

z Turn off the printer, press down HIGH SPEED key and turns on the printer.

The printer will print out the data from the computer in Hex Dump mode.

SCII TEST MODE

V e r s i o n : FB-600E V X . X X X X X X X X - X X - X X

SN: XXXXXXXXXXXXXXXXXXXX

!"#$%&’()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQR

!"#$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRS

"#$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRST

#$%&'()*+,-./0123456789:;<=>?@ABCDEFGHIJKLMNOPQRSTU

H PRINT MODE

V e r s i o n : FB-600E V X . X X X X X X X X - X X - X X

SN: XXXXXXXXXXXXXXXXXXXX

HHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHHH
