- 68 -
8.1.5 Envelope
Envelope specification should accord with the following table. In this specification, some envelopes are
beyond the support range because of shape, size and so on.
◆ Print Size and Printable Area
Note: 1. Envelope should not have solid edge (the folding part in both sides and the bottom).
2. Sample 2 Envelope need to be printed vertically.
3. Right margin doesn’t include seal lip, and the distance from printing content to the
bottom sunken line is not less than 5mm.
Envelope type Code name Length (mm) Width (mm) Support
B6 176 125 No
DL 220 110 No
ZL 230 120 No
C5 229 162
Yes (Note 1)
Sample 1
Envelope
C4 324 229 Yes
C6 162 114 No
DL 220 110 No
C5 229 162
Yes (Note 2)
Sample 2
Envelope
C4 324 229 Yes
Material
Envelope which is Grade or above
Weight
80
～ 120 g/m
2
Top 6.25 mm
Bottom 6.25 mm
Left 6.25 mm
Right
12 mm (Note 3)
Non-guaranteed
Area
From pulp position 5 mm
Protrusive part
