94 AutoFarm GPS AutoSteer
Final Hardware Installation Checklist
System Installation Checklist
Hydraulic Installation Checklist
AutoSteer Performance Checklist
Note: See the Calibration and Tuning Notes chapter for additional information.
1. Wheel Angle Sensor Installed and all fasteners are tight.
2. Monitor Bracket Installed and all fasteners are tight.
3. Roof rail is installed and all fasteners are tight.
4. SA Module is installed and all fasteners are tight.
5. All cable ends are connected.
6. All cables are secured with cable ties.
7. Roof Module locking pin is installed.
1. Valve bracket is installed and all fasteners are tight.
2. Valve is installed and all fasteners are tight.
3. All hose fittings are tight.
4. Check for oil leaks on all hydraulic connections.
5. All hoses are routed and secured with cable ties.
6. Adjust the AutoFarm relief valve.
7. Measure the standby pump pressure. Value_______________
8. Measure the maximum pump pressure in AutoSteer mode. Value_______________
9. Manual steering is normal after the AutoSteer installation.
1. Complete AutoFarm system calibration.
2. Complete AutoFarm system tuning.
3. Check total wheel angle sensor counts. Value_______________
4. Line acquisition is satisfactory.
5. On-line steering is satisfactory.
6. Manual override (kick-out) is working.
7. Steering speed from lock-to-lock is satisfactory. Value___________Sec.
8. Measure the MAX RATE LEFT. Value_______________
9. Measured the MAX RATE RIGHT. Value_______________
