38 AutoFarm GPS AutoSteer
Valve Type Installation Procedures
Pre-Startup Hydraulic Installation Checklist
1. Valve bracket bolts are tight.
2. Mounting screws securing the valve are tight.
3. Pressure hose is connected to correct port on AutoFarm Valve and vehicle.
4. Tank hose is connected to correct port on AutoFarm valve and vehicle.
5. LS-OUT hose connected to correct port at both ends.
6. LS ORBITROL hose is connected correctly at both ends.
7. Right steer hose is connected correctly at both ends.
8. Left steer hose is connected correctly at both ends.
9. Pressure transducer installed and tight.
10. Check that all hose fittings are tight.
11. Check hose routing and ensure cable ties are on all hoses.
12. Ensure all hoses are clear of moving parts, such as the engine drive shaft and front axle shaft.
13. SAM harness is connected to the two valve connectors.
14. 5000psi pressure gauge is installed on the valve test port.
