Hardware Installation Guide 9
Installation Procedure Outline
Note: The bracket kit includes general purpose brackets and hardware that you may modify to fit your vehicle. You may
choose to fabricate special brackets for improved implementation on your vehicle.
Installation Procedure Outline
Follow the installation process step order described below. Use the step-by-step installation instructions provided in this
manual.
1. Verify shipped components.
2. Install the Hydraulic Valve Assembly.
3. Install the Hydraulic Hoses.
4. Install the Wheel Angle Sensor.
5. Install the SA Module.
6. Install the Roof module.
7. Install the User Terminal.
8. Install the Main Cable Harness.
9. Ensure all connectors are properly coupled.
10. Power ON the AutoFarm system.
11. Calibrate the tractor.
12. Tune the tractor.
13. Verify installation and system operation.
Note: The system interconnect cable diagram in the Cable Diagram on page 10 section of this chapter shows the A5
AutoSteer electrical connections.
