82 AutoFarm GPS AutoSteer
Attach the Cable to the SA Module
Attach SA Module Cable Harness to Main Cable Harness
Route the SA Module cable into the cab through the rubber plug under the right side of rear window and attach both
connectors to the main cable harness. See
Figure 9-7 and Figure 9-8.
Note: The two connectors on the main cable harness must exit the cab to connect to the SAM Module cable.
Figure 9-7 Main Cable Rear Window Pass-Through
