AutoFarm A5 - Installation Procedure

66 AutoFarm GPS AutoSteer
Installation Procedure
Figure 7-2 User Terminal (rear view)
Installation Procedure
Some tractors have existing threads on the cab post for securing accessories. The threads can be under plastic caps or behind
plastic panels on some machines.
Unscrew the threaded plastic hole covers from the cab post. See Figure 7-3.
Mounting Bracket
Main Harness Cable
Connection
Viewing Angle
Adjustment
User Terminal
Mounting Plate
(Vesa 100)
