Hardware Installation Guide 35
Valve Type Installation Procedures
Adjusting the AutoFarm Relief Valve
The AutoFarm steering valve has a built-in Load Sense relief valve that limits the maximum pump pressure when
AutoSteering. The relief valve must be adjusted after you have completed the hydraulic installation and before you turn on
AutoSteer. The AutoFarm system must be fully installed and functional before you can adjust the relief valve.
Note: The relief valve in Figure 3-20 is shown on a bench without the hydraulic hoses connected for ease of viewing the
adjustment process. When you adjust the relief valve, it is done with the valve mounted on the vehicle and the hydraulic
hoses connected.
Figure 3-20 AutoFarm Relief Valve Adjustment
WARNING
To prevent the vehicle from running over a person, you must
never leave the vehicle while the GPS steering system is
engaged. Do not have people around the vehicle while the
engine is running.
