Hardware Installation Guide 15

Steering Valve Installation

This Steering Valve Installation chapter information is provided in the following sections:

• Steering Valve Overview

• Specifications

• Valve Hose Adapter Connections

• Valve Covers

• Mounting Hole Patterns

• Steering Valve Bracket Installation

• Valve Installation Guidelines

• Bracket Mounting Examples

• Example Bracket Installation Procedure

• Steering Valve Installation Procedure Overview

• Valve Type Installation Procedures

• Closed Center Load Sense Orbitrol Installation

• Closed Center Load Sense Power Beyond Installation

• Pressure Transducer

• Adjusting the AutoFarm Relief Valve

• Pre-Startup Hydraulic Installation Checklist

Steering Valve Overview

The steering valve installation requires custom hoses to fit each type of vehicle. Use only high quality hydraulic hoses rated

for 3000 psi or more. Do not mix hose fittings and hoses of different brands. Assemble hoses and crimp fittings following the

hose manufacturer’s recommendations. Use only steel hose adapters rated for 3000 psi or more. Use hose fittings that match

the type of fittings found on the machine.

Specifications

Table 3-1 Steering Valve Specifications

Function Data

Description Valve Steering

Part Number 200-0457-01

Application Wheeled vehicles with 12 volt electrical system

requiring steering oil flow up to 5.8 GPM.

Manifold Id 630AA00108A
