62 AutoFarm GPS AutoSteer
Roof Module Installation Tasks
Connect the Main Harness to the Roof Module connector. Rotate the connector sleeve clockwise to engage the connector. See
Figure 6-9.
Figure 6-9 Connecting the Main Harness to Roof Module
CAUTION
The GPS steering system must be powered OFF when
installing or removing the roof module.
CAUTION
The supplied roof module locking pin or a padlock must be in
place whenever the vehicle is in operation to prevent the
roof module from releasing from its bracket.
WARNING
To avoid electrical shock hazards, remove the roof module
from the vehicle before driving under low structures or low
electrical power lines.
