AUTOFLAME Mk8 MM Installation And Commissioning Guide

7 Remote Control
Page 116 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
Address Description Type
30101 Load Index Read analogue
 Firing rate %
30102 Firing Status Read analogue
 0 = Non-modulating, 1 = Modulating
 Returns value 0 single point change, fuel flow metering and commissioning
30104 Burner Rating Read analogue
 MW x 10
 Metric units determined from fuel flow metering
30105 Actual Value Read analogue
 Metric: temperature
O
C, pressure Bar x 10, low pressure Bar x 100
 Imperial: temperature
O
F, pressure PSI, low pressure PSI x 10
30106 Required Value Read analogue
 Metric: temperature
O
C, pressure Bar x 10, low pressure Bar x 100
 Imperial: temperature
O
F, pressure PSI, low pressure PSI x 10
30107 Selected Fuel Read analogue
 0 = Fuel 1, 1 = Fuel 2, 2 = Fuel 3, 3 = Fuel 4
30109 Channel 1 Position Read analogue
 Degrees x 10
 Range is -6.0
O
to 96.0
O
30110 Channel 2 Position Read analogue
 Degrees x 10
 Range is -6.0
O
to 96.0
O
30111 Channel 3 Position Read analogue
 Degrees x 10
 Range is -6.0
O
to 96.0
O
30112 Channel 4 Position Read analogue
 Degrees x 10
 Range is -6.0
O
to 96.0
O
30113 MM Error Number Read analogue
 0 = System is does not have an error, N = error number, check error codes
30114 Multi-Burner Id Read analogue
 MM Id number set in option 44
30115 EGA Current O2 Value Read analogue
 % x 10
30116 EGA Current CO2 Value Read analogue
 % x 10
30117 EGA Current CO Value Read analogue
 ppm x 10
30118 EGA Current Exhaust Gas Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30119 EGA Current Efficiency Value Read analogue
 % x 10
30120 EGA Current NO Value Read analogue
 ppm x 10
