AUTOFLAME Mk8 MM Installation And Commissioning Guide

7 Remote Control
04.09.2016 Mk8 MM Expansion Features Installation and Set-Up Guide Page 117
Address Description Type
30121 EGA Current SO2 Value Read analogue
 ppm x 10
30122 EGA Commissioned O2 Value Read analogue
 % x 10
30123 EGA Commissioned CO2 Value Read analogue
 % x 10
30124 EGA Commissioned CO Value Read analogue
 ppm x 10
30125 EGA Commissioned Exhaust Gas Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30126 EGA Commissioned Efficiency Value Read analogue
 % x 10
30127 EGA Commissioned NO Value Read analogue
 ppm x 10
30128 EGA Commissioned SO2 Value Read analogue
 ppm x 10
30129 EGA Error Code Read analogue
 0 = EGA does not have a fault, N = EGA error
30130 Minimum Remote Setpoint Read analogue
 Metric: temperature
O
C, pressure Bar x 10, low pressure Bar x 100
 Imperial: temperature
O
F, pressure PSI, low pressure PSI x 10
30131 Maximum Remote Setpoint Read analogue
 Metric: temperature
O
C, pressure Bar x 10, low pressure Bar x 100
 Imperial: temperature
O
F, pressure PSI, low pressure PSI x 10
30132 Current Flow Thousands Read analogue
 Metric kW, imperial MMBTU/hr x 1000
 Remainder after whole number of MW or MMBTU/hr x 1000 taken away. E.g. 1.5MW gives
500 value and 15.1MMBTU/hr gives 100 value
30133 Current Flow Millions Read analogue
 Metric MW, imperial MMBTU/hr
 Whole number of MW or MMBTU/hr. E.g. 1.5MW gives 1 value and 15.1MMBTU/hr gives
15 value
30134 Fuel 1 Flow Total Thousands Read analogue
 Metric kW/hr, imperial MMBTU/hr
 Remainder after whole number of MW/hr or MMBTU x 1000 taken away, x 1000. E.g.
1.5MW/hr gives 500 value and 15.1MMBTU gives 100 value
30135 Fuel 1 Flow Total Millions Read analogue
 Metric MW/h, imperial MMBTU
 Whole number of MW/hr or MMBTU. E.g. 1.5MW/hr gives 1 value and 15.1MMBTU gives
15 value
30136 Fuel 1 Flow Total Billions Read analogue
 Metric GW/hr, imperial MMBTU / 1000
 Whole number of GW/hr or MMMBTU E.g. 1.5MW/hr gives 0 value and 15.1MMBTU gives 0
value
