AUTOFLAME Mk8 MM Installation And Commissioning Guide

7 Remote Control
Page 118 Mk8 MM Expansion Features Installation and Set-Up Guide 04.09.2016
Address Description Type
30137 Fuel 2 Flow Total Thousands Read analogue
 Metric kW/hr, imperial MMBTU/hr
 Remainder after whole number of MW/hr or MMBTU x 1000 taken away, x 1000. E.g.
1.5MW/hr gives 500 value and 15.1MMBTU gives 100 value
30138 Fuel 2 Flow Total Millions Read analogue
 Metric MW/h, imperial MMBTU
 Whole number of MW/hr or MMBTU. E.g. 1.5MW/hr gives 1 value and 15.1MMBTU gives
15 value
30139 Fuel 2 Flow Total Billions Read analogue
 Metric GW/hr, imperial MMBTU / 1000
 Whole number of GW/hr or MMMBTU E.g. 1.5MW/hr gives 0 value and 15.1MMBTU gives
0 value
30140 Fuel 3 Flow Total Thousands Read analogue
 Metric kW/hr, imperial MMBTU/hr
 Remainder after whole number of MW/hr or MMBTU x 1000 taken away, x 1000. E.g.
1.5MW/hr gives 500 value and 15.1MMBTU gives 100 value
30141 Fuel 3 Flow Total Millions Read analogue
 Metric MW/h, imperial MMBTU
 Whole number of MW/hr or MMBTU. E.g. 1.5MW/hr gives 1 value and 15.1MMBTU gives
15 value
30142 Fuel 3 Flow Total Billions Read analogue
 Metric GW/hr, imperial MMBTU / 1000
 Whole number of GW/hr or MMMBTU E.g. 1.5MW/hr gives 0 value and 15.1MMBTU gives
0 value
30143 EGA Current Ambient Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30144 EGA Current Delta Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30145 EGA Commissioned Ambient Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30146 EGA Commissioned Delta Temperature Read analogue
 Metric: temperature x 10
O
C
 Imperial: temperature x 10
O
F
30147 UV Counts Read analogue
 Returns value displayed on MM
30148 IR Counts Read analogue
 Returns value displayed on MM
30149 Flame Switch Status Read analogue
 0 = Off, 1 = On
30150 EGA Current NO2 Value Read analogue
 ppm x 10
30151 EGA Commissioned NO2 Value Read analogue
 ppm x 10
