Chapter 3: Configuration and Parameters
Parameter Summary for Touchscreen Setup – “I/O” Category (continued)
– Group Parameter Units Range
Read /
Write
Modbus
Default
Setting
User
Setting
PNU Hex
Category – I/O
(P13)
Analog
Outputs
[detailed
info starts
page 3–51]
P13�0 – Analog Output Type toggle 0–10V / 4–20mA R/W 8960 2300 0–10V
P13�1 – Select Function –
Off
Current Measured
Overload
Overload SCR
P-Total
R/W 9024 2340 OFF
P13�2 – Scaling Level – 0 to 16,384 R/W 9088 2380 0
(P14)
[details
page 3–52]
P14�0 – PTC Motor Thermistor Trip toggle OFF / ON R/W 53794 D222 OFF
parameTers from “moniTor” menu CaTegory – summary
Summary – Parameters for Touchscreen Setup – “Monitor” Category
Category – Monitor
Group Parameter Units Range
Read /
Write
Modbus
Default
Setting
User
Setting
Address Hex
(P15)
Monitoring
[detailed info
starts page
3–53]
P15�0 – Line Frequency Hz 45 to 65 Read 32000 7D00 n/a –
P15�1 – Phase Rotation – L1-L2-L3 or L1-L3-L2 Read 32064 7D40 L1-L2-L3 –
P15�2 – I1 A 0 to 10,000 Read 33536 8300 0 –
P15�3 – I2 A 0 to 10,000 Read 33538 8302 0 –
P15�4 – I3 A 0 to 10,000 Read 33540 8304 0 –
P15�5 – Current I rms A 0 to 10,000 Read 32896 8080 0 –
P15�6 – V rms (Approx) V 0 to 500 Read 32960 80C0 0 –
P15�7 – Real Power Factor – 0 to 1 Read 33024 8100 0 –
P15�8 – True Power P kW 0 to 10,000 Read 34688 8780 0 –
P15�9 – Apparent Power S kVA 0 to 10,000 Read 34816 8800 0 –
P15�10 – Reactive Power Q kVAR 0 to 10,000 Read 34944 8880 0 –
P15�11 – iERS Saving Level % 0 to 100 Read 35008 88C0 0 –
P15�12 – Delay Angle degree 0° to 55° Read 22400 5780 0 –
P15�13 – Backstop degree 0° to 55° Read 23040 5A00 0 –
P15�14 – Delay Max degree 0° to 55° Read 22464 57C0 0 –
P15�15 – Pres PF Degrees degree 0° to 90° Read 21824 5540 0 –
P15�16 – Ref PF Degrees degree 0° to 90° Read 21760 5500 0 –
P15�17 – Start Saving Level % 50% to 80% of mtr FLA Read 21320 5348 80% –
P18�0 – Last Peak (Start) Current A 0 to 10,000 Read 38400 9600 0 –
P15�18 – HeatSink Temp °C -20°C to 80°C Read 36544 8EC0 ambient –
P15�19 – Motor Thermistor – 0 to 1024 Read 10432 28C0 0 –
P15�20 – Overload % 0 to 100 Read 33408 8280 0 –
