Autronica Autro Safe BS-310 - Location of Fuses

Internal Cable Connections
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Rev. J, 2011-12-06,
Autronica Fire and Security AS
2.3 Location of Fuses
2.3.1 Fuses on Power Supply, BSS-103A/02
 Remove the fuses F1 and F2 on the Power Supply.
Do not replace the fuses until commissioning of the system.
POWER OFF!
Fuse No. Size Type Slow/Fast Protecting
F1 2 A T2AH/250V AC Slow (T) Mains
F2 6,3 A F6,3AH/250V AC Fast (F) Battery
F3 1 A T1AL/250V AC Slow (T) External 24V DC
!
Remove fuses
F1 and F2.
Do not replace
the fuses until
commissioning
of the system.
F3 F2 F1
