Installing I/O Modules
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Rev. J, 2011-12-06,
Autronica Fire and Security AS
3.11 Input Module, BSE-320
Screw Terminal nr. Signal
1 IN1
2 IN2
3 IN3
4 IN4
5 IN5
6 IN6
7 IN7
8 IN8
9 n.c.
10 INx-power supply
Common source to all inputs (+)
Schematics
