Autronica Autro Safe BS-310 - Guidelines - Unknown Cable Layout

Guidelines for the Installation
and Addressing of Loop Units
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Rev. J, 2011-12-06,
Autronica Fire and Security AS
6.5 Guidelines - Unknown Cable Layout
Step Installation Configuration Known Parameters
1
Obtain a detailed drawing of
the building premises.
(The cable layout is not shown,
as it is unknown).
2
Mark all Tag Names on the
drawing (at each loop unit
location).
3
Enter all Tag Names into the
AutroSafe Configuration Tool.
At this point the system
knows the Tag Names.
4
Print out the list of all Tag Names.
5
Install the sockets at all loop
unit locations according to the
drawings.
Mount each loop unit at its
respective location.
Remove and paste the sticker
with the Production Number in
its correct position on the list,
beside the corresponding Tag
Name.
6
Enter each Production Number
into the AutroSafe Configuration
Tool beside its corresponding Tag
Name.
When all Production
Numbers are entered
into the Configuration
Tool, the system will
know all three
parameters.
