Autronica Autro Safe BS-310 User Manual

Installing I/O Modules
Installation Handbook, AutroSafe Interactive Fire Alarm System, Release 3, 116-P-ASAFE-FA/DE,
Rev. J, 2011-12-06,
Autronica Fire and Security AS
3.6 Communication Module, BSL-310
Connector on ribbon Cable 1
To Connection Module BSF-310B
Signal
1 INT
2 RS_GND
3 TX
4 RS_GND
5 N.C. (GND)
6 RS_GND
7 RX
8 RS_GND
9 CTS
10 RS_GND
Connector on ribbon Cable 2
To Power Module BSS-103A/02
Signal
1 TEST
2 N.C.
3 N.C. GND
4 MAINS_OK
5 N.C.
6 APPLY_LOAD
Schematics
BSF-310B
Connection
Module
BSL-310
BSS-103A/02
Power Supply
Cable 1
Cable 2
