General Description
System Description and Operation, AutroSafe Maritime Gas Detection, 116-P-BS420MG/XGB, Rev. E, 2019-12-10,
Autronica Fire and Security
Page 8
4.2.3 AutroFieldBus
AutroFieldBus is used to connect the BSD-321 protocol converter,
power supplies and the BSD-340 Powerloop driver module to the
AutroSafe Panel. An AutroFieldBus interface communicates with all
these devices.
The BSD-321 module provides a way to remotely connect I/O
modules to an AutroSafe panel.
Point Gas Detectors and 4-20mA interfaced gas detectors can be
connected to the PowerLoop driver, BSD-340, via a 2-wire loop.
The BSD-340 PowerLoop module and the BSD-321 module can be
powered locally. They can be located inside the cabinet or in the field,
in close proximity to the gas detectors – thus further reducing cable
requirements. Refer to PowerLoop description in Chapter 0.
4.3 Response Time
The system’s response time for the first alarm entering the system is ≤
2 seconds, for all type of gas detectors.
The maximum response time from first alarm entering the system until
it is processed and reported via AutroCom is ≤ 2 seconds, refer to
table below.
Signal
Hardware
Response time
Alarm
Output module
< 2 sec
Alarm
AutroCom
< 2 sec
Alarm
Panel display
< 1 sec
Analoge value
AutroCom
2 sec (0.5 Hz)
4.4 Configuration
Configuration files for AutroSafe are produced by means of the
AutroSafe Configuration Tool. This is a special software package that
runs on any modern PC with Windows. Refer to the AutroSafe
Configuration Help System integrated into the AutroSafe Configuration
Tool for details.
