Panel Overview
System Description and Operation, AutroSafe Maritime Gas Detection, 116-P-BS420MG/XGB, Rev. E, 2019-12-10,
Autronica Fire and Security
Page 32
More Events Button
6.8.2 Information Panel
Front Push Buttons
Button
Designation
Access
Level
Mute Panel
(black)
Used to mute the panel, i.e. silence the internal
buzzer. Timeout.
(Information Loop Panel: The Mute Panel button is
named Silence Buzzer. The Backlight Brightness can
be toggled between high and low by holding the
Silence Buzzer button for 5 seconds until audible
beep (access level 1).
1
Next Window
(red)
Used to step to the next condition window (only
windows with active information are displayed). After
all windows have been shown, the first window is
displayed. When a timeout on no operation has been
ended, the highest prioritized window is displayed.
1
Lamp Test
(green)
Used for testing the LED indicators. All indicators are
lit for 5 seconds, and the LCD (display) will show a
pattern to verify all pixels (will turn all white, then all
black).
1
More Events
(black)
Used to scroll pages of information related to the
selected condition window, if there are more events
than the display can show.
1
Front Push Buttons
