Panel Overview
System Description and Operation, AutroSafe Maritime Gas Detection, 116-P-BS420MG/XGB, Rev. E, 2019-12-10,
Autronica Fire and Security
Page 31
6.8.1.3 Alphanumeric Keyboard
The alphanumeric keyboard includes the numbers 1 to 9, the letters a
to z and other feature keys (see table below).
The number 0.
Used to enter a space between words.
6.8.1.4 Manoeuvre Buttons
When the cursor is on a list
item.
The properties of a selected unit is
shown.
The selected menu page on the display is
shown if the item is a submenu.
Accepts the selected function if the item
is a function.
When the cursor is on an
item in a single select list.
Used to select/approve a selection
(parameter) or return.
Used to scroll lines up or down.
Used to change numerical values.
Used to cancel an input character
(backspace).
