Autronica AutroSafe Maritime Gas Detection - Page 74

Gas Commands
System Description and Operation, AutroSafe Maritime Gas Detection, 116-P-BS420MG/XGB, Rev. E, 2019-12-10,
Autronica Fire and Security
Page 68
Step
Actions to be taken
Display Indication
4
To select INHIBIT POINT, press 1.
5
Use the keyboard to enter text into the input box
-
OR ,- as shown in this example:
To select a point, press
then scroll downwards or upwards by pressing
6
To accept the selected point, press
7
Enter hours, then press
Enter minutes, then press
To execute the command (accept the inhibit
time), press
once more
SERVICE
19:23
INHIBIT POINT
1ab12
1mc3
1mc6
1od1
1od2
1od4
1od5
SERVICE
19:23
INHIBIT POINT
1ab12
1mc3
1mc6
1od1
1od2
1od4
1od5
SERVICE
19:23
INHIBIT POINT
1ab12
1mc3
1mc6
1od1
1od2
1od4
1od5
SERVICE
19:23
INHIBIT POINT
1ab12
Inhibit Time:
Hours:
Min.:
SERVICE
19:23
INHIBIT POINT
1ab12
Inhibit Time:
Hours:
Min.:
